10.1-inch Capacitive Touch Panel | HY4635-N068 Chip | I2C CTP | 6-pin FFC

This 10.1-inch capacitive touchscreen, the CTP-H101A9, redefines the boundaries of human-computer interaction with its groundbreaking design. The ultra-thin panel, like an invisible technological skin covering the surface of the device, boasts industrial-grade reliability within its extreme thinness. Its unique lamination process eliminates traditional double-sided tape, achieving a seamless fit and bringing the displayed content to life with a high light transmittance of ≥85%, making every frame at 1024×600 resolution pop.

Powered by the HY4635-N068 controller chip, this capacitive touch panel achieves submillimeter tracking accuracy, even with fast swipes or complex gestures. The minimalist black-framed design boasts a wide operating temperature range of -20°C to 70°C, maintaining consistent touch accuracy even in extreme operating conditions, from -30°C to 80°C. This touch panel includes an FFC cable, and its I2C communication interface makes it highly compatible with displays.

This touch panel is compatible with the high-brightness TFT LCD: TFT-H101A9WSIFTKN40. When the touch panel and display are seamlessly combined, they create a TFT display with touchscreen functionality: TFT-H101A9WSIFTKC40.
